High-performance infrared imaging normally requires exotic materials or cryogenic cooling, making it too costly for widespread commercial or security use. Conventional CMOS sensors—the same ones powering everyday smartphone and consumer cameras—cannot detect short-wave or mid-wave infrared light, leaving a major capability gap. The result is a divide between inexpensive visible-light imaging and expensive, specialized thermal systems used in defense, aviation, and industrial inspection.
Researchers at the Beijing Institute of Technology have developed a promising bridge between those worlds: a snake-inspired infrared-to-visible upconverter that attaches directly to a standard CMOS sensor and enables 4K thermal imaging at room temperature. The approach is designed to mimic the heat-sensing pit organs of snakes, which detect tiny temperature differences in low-light environments.
The team’s core challenge was eliminating the noise that overwhelms infrared detectors operating without cooling. To solve this, they built a barrier heterojunction using mercury telluride colloidal quantum dots, supported by zinc oxide and polymer layers that block dark current while allowing signal carriers to pass. This combination preserves sensitivity to SWIR (short-wave-infrared) and MWIR (mid-wave-infrared) wavelengths without the need for bulky thermal management hardware.
According to Interesting Engineering, the device includes a co-hosted light-emission layer that converts captured infrared photons into visible light, which standard CMOS pixels can record. By carefully balancing charge transport within the upconverter, the researchers greatly increased efficiency—turning faint IR signals into clear, high-resolution images.
Integrated onto an 20.3-cm CMOS wafer, the prototype produced 3840 × 2160-pixel infrared images with a tiny 1.55-micron pixel pitch. In demonstrations, the system successfully imaged thermal patterns, viewed objects through silicon wafers, and detected heat signatures normally invisible to standard optics. The upconverter extends sensor coverage out to 4.5 microns, effectively widening a camera’s spectral range by fourteenfold.
For defense and homeland security, this kind of low-cost, high-resolution infrared capability could be transformative. Thermal imaging is essential for night operations, perimeter monitoring, target detection through haze or smoke, and surveillance in visually degraded environments. Today, such systems remain expensive and limited in availability; a CMOS-compatible solution could enable wider deployment across unmanned platforms, handheld devices, and fixed-site sensors.
By borrowing a biological solution and translating it into semiconductor engineering, the researchers have demonstrated a viable path toward accessible, mass-produced thermal imaging—bringing snake-like perception closer to everyday hardware.
The study was published in Light: Science & Applications.
